Mounted Ball Bearings ECO-75M

  • Baldor-Dodge
  • ECO-75M

  • 782476750091
  • 0.26 LB
  • Crossville, TN - DC
  • Medium Duty
Contact NowWhatsApp
Agicb industrial parts LLP

Agicb industrial parts LLPChina

  • Agicb industrial parts LLP2020-07-10 09:46:19
    Welcome to my shop! Glad to serve you! Please send your question!
Price Inspection Certificate Product Specifications Company Profile

Product Details

UPC: 782476750091 Ship Weight: 0.26 LB Manufacturing Plant Location: Crossville, TN - DC
Bearing Duty: Medium Duty

Product Description

Baldor-Dodge ECO-75M bearing Size Chart (mm/inches)

Bearing number6221NR
Size (mm)105x190x36
Bore Diameter (mm)105
Outer Diameter (mm)190
Width (mm)36
d105 mm
D190 mm
B36 mm
C36 mm
a5.69 mm
b3.5 mm
f3.1 mm
r min.2.1 mm
r1 min.0.5 mm
D1183.64 mm
D2202.9 mm
Weight3.76 Kg
Basic dynamic load rating (C)133 kN
Basic static load rating (C0)104 kN
(Grease) Lubrication Speed3200 r/min
Bore TypeCylindrical Bore
ConfigurationSingle Row
EnclosureSnap Ring Groove with Snap Ring
Bore Size105 mm
Outside Diameter190 mm
Width36 mm
Fillet Radius/Chamfer2.1 mm
r10.5 mm
Snap Ring Width3.1 mm
Snap Ring Outside Diameter202.9 mm
D1 (max)183.6 mm
a (max)5.7 mm
b (min)3.5 mm
Dynamic Load Rating133,000 N
Static Load Rating104,000 N
Limiting Speed - Grease3,400 rpm
Limiting Speed - Oil4,000 rpm
Factor fo14.3
Radial Clearance0.015 to 0.041 mm
da (min)117 mm
Da (max)178 mm
Dx (min)205 mm
ra (max)2 mm
Cy (max)8.4 mm

Mounted Ball Bearings ECO-75M

Mounted Ball Bearings ECO-75M Cad Models
